Professional FM200 Fire System Automatic Refilling Equipment for Industrial Safety

Dettagli del prodotto

Luogo di origine: Guangzhou, Cina

Marca: XINGJIN

Certificazione: CCC,CAC,ROHS

Numero di modello: XJ-QEO-006

Termini di pagamento e di spedizione

Quantità di ordine minimo: 1 sistema di impostazione

Prezzo: Pricing based on quantity

Imballaggi particolari: Scatola di legno o scatola esterna in compensato con sacca a bolle o carta

Tempi di consegna: Secondo la quantità del prodotto

Termini di pagamento: T/T, L/C

Capacità di alimentazione: 3000 set/mese

Ottieni il miglior prezzo
Dettagli del prodotto
Evidenziare:
Agente di estinzione applicabile:
Perfluoroesanone, azoto
Pressione massima di riempimento:
6.0 MPa
Intervallo di decompressione dell'azoto:
0 ~ 10 MPa regolabile (comunemente usato: 4,2 MPa, 5,6 MPa)
Pressione di uscita del farmaco:
0 ~ 3.6 MPa
Grado sottovuoto:
≤ -0,09 MPa
Riempimento dell'allarme di pressione:
0 ~ 10 MPa (regolabile, la spia di allarme si accende quando si raggiunge il valore impostato)
Densità di riempimento:
≤ 1420 kg/m³
Riempimento della precisione:
± 0,5%
Temperatura ambiente:
0 ~ 50 ℃
Requisiti di alimentazione:
AC 220V,50Hz
Dimensione dell'attrezzatura:
720 × 800 × 1280 mm (escluso il corridore)
Discussione di connessione esterna:
Discussioni per ingresso del reagente e uscita e interfaccia di azoto: M22 × 1.5
Agente di estinzione applicabile:
Perfluoroesanone, azoto
Pressione massima di riempimento:
6.0 MPa
Intervallo di decompressione dell'azoto:
0 ~ 10 MPa regolabile (comunemente usato: 4,2 MPa, 5,6 MPa)
Pressione di uscita del farmaco:
0 ~ 3.6 MPa
Grado sottovuoto:
≤ -0,09 MPa
Riempimento dell'allarme di pressione:
0 ~ 10 MPa (regolabile, la spia di allarme si accende quando si raggiunge il valore impostato)
Densità di riempimento:
≤ 1420 kg/m³
Riempimento della precisione:
± 0,5%
Temperatura ambiente:
0 ~ 50 ℃
Requisiti di alimentazione:
AC 220V,50Hz
Dimensione dell'attrezzatura:
720 × 800 × 1280 mm (escluso il corridore)
Discussione di connessione esterna:
Discussioni per ingresso del reagente e uscita e interfaccia di azoto: M22 × 1.5
Descrizione del prodotto

Heptafluoropropane fire extinguishing agent filling equipment


Product Overview:

Heptafluoropropane fire extinguishing agent filling equipment is a professional device that integrates high efficiency, safety and precision, and is suitable for
  Heptafluoropropane fire extinguishing agent filling. The equipment is equipped with nitrogen pressure reduction, filling pressure alarm, vacuum pumping system and weight reporting
  The alarm node reserves interfaces to support multiple gas cylinder specifications, ensuring the airtightness and accuracy during the fire extinguishing agent filling process
Professional FM200 Fire System Automatic Refilling Equipment for Industrial Safety 0

Technical Parameter:

Project Parameter
Suitable Extinguishing Media FM200(HFC-227ea),Nitrogen
Maximum Filling Pressure 5.6 MPa
Nitrogen Pressure Reduction Range 0~ 10 MPa adjustable (commonly used: 2.5 MPa, 4.2 MPa, 5.6 MPa)
Drug Output Pressure 0~3.6 MPa
Vacuum Degree ≤ -0.09 MPa
Filling Pressure Alarm 0~ 10 MPa (Adjustable to set value, alarm warning light on)
Filling Density ≤ 950 kg/m³
Filling Accuracy ±0.5%
Ambient Temperature 0~50℃
Power Requirements AC 220V ,50Hz
Equipment Size 720×800×1280 mm (Excluding the wheel)
External Connection Thread Drug inlet and outlet threads and nitrogen interface: M22 × 1.5
Other Reserved weight alarm indicator interface (requires external intelligent electronic weighing device)

Professional FM200 Fire System Automatic Refilling Equipment for Industrial Safety 1

 Equipment valve body function:

F1 pressure reducing valve Control the pressure of nitrogen entering the system to ensure stable and safe filling process.
F2 pressure relief valve

Release excess pressure in emergency situations to protect equipment and gas

cylinders from high pressure damage.

F3 Pharmaceutical Storage Valve Control the pipeline for the flow of fire extinguishing agent from the storage tank to the filling cylinder.







F4 nitrogen storage valve Control the entry of nitrogen from the storage tank into the equipment pipeline to provide pressure for the filling of fire extinguishing agents.
F5 gas cylinder valve

Used to connect fire extinguishing agent cylinders and control the opening or closing

of cylinder fluid pipelines.

F6 vacuum valve Used to open or close the air inside the extracted gas cylinder, reduce the pressure inside the cylinder, and ensure the purity of the fire extinguishing agent filling.
